Nvidia RTX 2060 Founders Edition 6GB Review

Rating: 8.5.

Last updated on June 30th, 2019 at 09:44 am

Following on from the launch of the RTX 2080 and 2080 Ti in September, and then the RTX 2070 a month later, it’s not exactly a surprise that the RTX 2060 is the next Turing-based graphics card to be released by Nvidia. Essentially a cut-down RTX 2070, based on the same TU106 GPU, this card does indeed have the necessary RT and Tensor cores to make use of RTX features like ray tracing and DLSS – contrary to some rumours, this is very much an RTX card, not a return to GTX nomenclature.

Just how effective the card is when it comes to real time ray tracing, we will have to see – and there is still only one game on the market that actually supports the technology. But with this Founders Edition retailing for $349 – or £329 for us in the UK – is the all-round performance enough to justify the price?

Watch video via Vimeo (below) or over on YouTube at 2160p HERE


With its previous RTX 20-series cards, Nvidia complicated matters by releasing reference specifications for its cards, but then selling the Founders Edition models with a factory overclock – so they are not reference cards. If you want a reference-clocked RTX 2080, for instance, you would have to buy a cheaper aftermarket card.

With the RTX 2060 Founders Edition 6GB, the company has changed tack again – so this Founders Edition is based on reference speeds, thus it does not come factory overclocked. Third party vendors like ASUS, Gigabyte and MSI will be releasing their own reference and factory overclocked models very shortly.

That means baseline RTX 2060s – which at the time of writing, only seem to be available with 6GB VRAM – will be clocked at 1680 MHz, though GPU Boost will still raise this frequency dynamically when the card is under load. It will be interesting to see what kind of factory overclocks Nvidia’s partners can supply with their custom cards.

GPU RTX 2080 (FE)  GTX 1080 RTX 2070 (FE)  GTX 1070  RTX 2060 (FE)  GTX 1060
SMs  46  20 36 15 30 10
CUDA Cores  2944 2560 2304 1920 1920 1280
Tensor Cores  368 N/A 288 N/A 240 N/A
Tensor FLOPS  85 N/A 63 N/A 51.6 N/A
RT Cores 46 N/A 36 N/A 30 N/A
Texture Units 184 160 144 120 120 80
ROPs 64 64 64 64 48 48
Rays Cast  8 Giga Rays/sec 0.877 Giga Rays/sec 6 Giga Rays/sec 0.65 Giga Rays/sec 5 Giga Rays/sec 0.44 Giga Rays/sec
RTX Performance  60 Trillion RTX-OPS  8.9 Trillion RTX-OPS 45 Trillion RTX-OPS 6.5 Trillion RTX-OPS 37 Trillion RTX-OPS N/A
GPU Boost Clock  1800 MHz  1733 MHz 1710 MHz 1683 MHz 1680 MHz 1708 MHz
Memory Data Rate 14 Gbps 10 Gbps 14 Gbps 8 Gbps 14 Gbps 8 Gbps
Total Video Memory  8GB GDDR6  8GB GDDR5X 8GB GDDR6 8GB GDDR5 6GB GDDR6 6GB GDRR5
Memory Interface   256-bit  256-bit 256-bit 256-bit 192-bit 192-bit
Memory Bandwidth  448 GB/sec  320 GB/sec  448 GB/sec 256 GB/sec 336.1 GB/sec 192 GB/sec
TDP  225W  180W 185W 150W 160W 120W

To give you a run over the rest of the specs, as mentioned the RTX 2060 uses a cut-down version of the TU106 GPU found in the RTX 2070. That means it has 6 less SMs, with a total of 30, with 1920 CUDA cores compared to the RTX 2070’s 2304. With Turing, each SM houses a single RT core, so 30 SMs = 30 RT cores for the 2060.

We have the same GDDR6 memory as all of the other RTX cards – meaning a 14 Gbps data rate – but obviously 6GB in capacity here. This operates over a 192-bit bus, and the total memory bandwidth is 336.1 GB/s.

Lastly, TDP for this Founders Edition card is rated at 160W, so we would expect other reference-clocked cards to have the same TDP, but factory overclocked models will probably be closer to 200W.
