Nvidia RTX 2060 SUPER Founders Edition 8GB Review

Rating: 8.0.

We've been hearing about ‘SUPER' ever since Nvidia posted a short teaser video at the end of May. Computex and then E3 came and went, with not a word from the company about what to expect. That all changes today, however, as Nvidia has announced three new ‘SUPER' versions of the RTX 2060, RTX 2070 and RTX 2080.

In this review we will be focusing on RTX 2060 SUPER, but we also have launch day coverage of RTX 2070 SUPER over here if you are interested. What makes this card SUPER, and is it any good?

The first thing you need to know about Nvidia's SUPER line up of cards, is that we are not really seeing anything we haven't seen before. By that I mean, for the 2060 and 2070 SUPER editions at least, Nvidia has simply taken its existing TU106 and TU104 GPUs, shaved off some SMs and called the end results ‘SUPER'. The rumours about faster 16Gbps GDDR6 memory have not turned out to be true for these cards.

In the case of the RTX 2060 SUPER, Nvidia has taken the TU106 GPU and disabled two SMs, giving a total of 34 and therefore 2176 CUDA cores. This positions it closer to the RTX 2070 than the actual RTX 2060, despite the naming. It also keeps the 8GB GDDR6 memory found on its bigger brother, so perhaps it is more accurate to think of it as a ‘2070 Lite' rather than ‘2060 SUPER', but it is what it is.

GPU RTX 2080 (FE)  RTX 2070 SUPER RTX 2070 (FE)  RTX 2060 SUPER  RTX 2060 (FE)
SMs  46  40 36 34 30
CUDA Cores  2944  2560 2304 2176 1920
Tensor Cores  368  320 288 272 240
Tensor FLOPS  85  72 63 57.4 51.6
RT Cores 46  40 36 34 30
Texture Units 184  160 144 136 120
ROPs 64  64 64 64 48
Rays Cast  8 Giga Rays  7 Giga Rays 6 Giga Rays 6 Giga Rays 5 Giga Rays
GPU Boost Clock  1800 MHz  1770 MHz 1710 MHz  1650 MHz 1680 MHz
Memory Data Rate 14 Gbps  14 Gbps 14 Gbps  14 Gbps 14 Gbps
Total Video Memory  8GB GDDR6  8GB GDDR6 8GB GDDR6  8GB GDDR6 6GB GDDR6
Memory Interface   256-bit 256-bit 256-bit  256-bit 192-bit
Memory Bandwidth  448 GB/sec 448 GB/sec  448 GB/sec   448 GB/sec 336.1 GB/sec
TDP  225W  215W 185W  175W 160W

The decision to present RTX 2060 SUPER as RTX 2070 minus one Texture Processing Cluster (each TPC houses 2x SMs) has other consequences, aside from the reduced CUDA core count. It also means the 2060 SUPER has less RT cores, with a total of 34, while its Tensor core count is bumped down from 288 to 272.

Out of the box clock speed is also relatively slow compared to other Turing cards, with a rated boost clock of 1650MHz. This is the reference speed, meaning the Founders Edition card we are reviewing today is a reference card rather than a factory overclocked model, but the likes of Gigabyte, ASUS, MSI will be releasing factory overclocked cards.

Lastly, as we already touched on, RTX 2060 SUPER has 8GB GDDR6 memory, again clocked at 1750MHz (14000MHz effective) – the same as every other RTX card available. This means memory speeds have not been increased for this SUPER card.
